Flash Tune Fuel/Modification Update - Focus ST

Flash Tune Fuel/Modification Update - Focus ST

Starting at: $60.00USD

Tuning form emailed to you after purchase for your mod list.

Read Your Choices Carefully!

Previous Flash Tune Order #:

These features will be set up later in the tuning form:
- Launch Control settings
- Flat Foot Shifitng (FFS) Enable/Disable
- Sound Symposer Enable/Disable
- Active Grill Shutter (AGS) Enable/Disable

Intakes, exhausts, intercoolers & BOVs included in base price:

Added Parts:

MUST MATCH to your previous Flash Tune order(s):

For E30 tunes ONLY (Includes Datalog Refinement)

High Torque E30 (+15-20 ft/lb)

Each option below will be added to a SPARE MAP SLOT if selected:

5-Way Map Features(SWITCHABLE):



Applies to all MAP SLOTS in a TUNE FILE:

Extra Options(NON-SWITCHABLE):



Choosing crackles will give you an additional TUNE FILE which
- Recommended: Aftermarket Turboback Exhaust
allows you to switch between Medium/Loud or Crackles/No Crackles
- NOT Recommended: Stock downpipe WITH stock catback
- Intensity of crackles HIGHLY DEPENDS on exhaust setup

Applies to all MAP SLOTS in a TUNE FILE. REFLASH to change:

STuned Crackles(NON-SWITCHABLE):

Spark Based Stratified Tuned Traction Control

Throttle calibration. Maximum power not affected:

Further tuning using data collected from your car:

*** Datalog Refinements will adjust your tune for your
specific car. This means the tune may be changed for safety
and/or power based on the data collected in the logs.
Datalogging instructions will be sent via e-mail. ***
Item is in stock

Description



This update requires us to re-make your tune from scratch. Please reselect the options that you had on your previous tune or any new options you would like.





The Details

This update gets your tune version to the latest spec AND accommodates your new modifications and fuel types.

  • If you have no new modifications and ONLY want to update your tune version to the latest spec click here.
  • If you want to keep your current version but want to add/change tune settings or features click here.

This update is for cars running the Stratified Flash Tune that want to tune for a different fuel type or have added new modifications such as:

  • Intakes
  • Exhausts
  • Intercoolers
  • Blow-off valves/by-pass valves
  • WMI (water-methanol injection) kits



Update History

Our current Flash Tune version (as of Jan 25, 2023) is 10.30.

Version 10.20 to 10.30:

           - Improved take-off smoothness in 1st gear
           - Reduced rev hang when shifting
           - Improved engine braking

Version 10.10 to 10.20:

           - Fueling delivery improvements

Version 10.00 to 10.10:

           - Smoother throttle tip-in

Version 9.00 to 10.00:

- More safe power and torque based on thousands of tunes and datalogs analyzed
- More adaptable wastegate strategy for modified cars

- Smoother tip-in and gear change strategies
- Reduced the likelihood of torque limit and fuel pressure too high codes

Version 8.10 to 9.00:

- Faster adapting, more responsive ignition timing, and knock management
- Idle dip improvement as the car comes to a stop
- Fuel system improvement to increase combustion efficiency
- Air fuel ratio targets optimized for pump gas and ethanol tunes
- Improved STuned traction control for less momentum loss during cornering.
- Added high torque (HT) E30 option (+15-20ft/lb from 2500-5000 RPM over regular E30)
- Replaced Medium crackles with Progressive Crackles.

Version 8.00 to 8.10:

- Added support for adjustable Launch Control, Flat Foot Shifting, and Driving Rev Limit

Version 7.10 to 8.00:

- Broadened torque curve at peak turbo efficiency
- Refined knock control response and adaptation
- Adjusted fueling response to lessen HPFP strain at peak torque
- Improved Rev Limiter response at redline to reduce engine strain if the rev limiter is hit
- Improved throttle response during takeoff
- Added throttle mapping options: linear, aggressive
- Added WMI support

Version 7.00 to 7.10:

- Better boost holding and higher sustained torque post spool.
- More consistent wide open throttle air-fuel ratios.
- Reduced cruise and idle AFR oscillation on vehicles with aftermarket downpipes.
- V2 "crackles and pops" for exhaust sound. Louder, crisper crackling that stops 1-3 seconds after lift. More audible with all exhaust setups. Less fuel is used during over-run with this iteration. See the video below.



Version 6.10 to 7.00:

- Crisper, more direct shifting and take-off
- Faster fuel enrichment response and high-pressure fuel pump pressure improvement
- Added further protection from high RPM overboost conditions due to wastegate failure
- Option to add "crackles and pops" to exhaust sound



Version 6.00 to 6.10:

- Throttle response improved to smoothen take-off and clutch engagement in 1st gear
- Tighter load and fuel controls to prevent fuel pressure drops, especially in very cold climates
- Timing compensation changes to reduce acceleration tip-in knock

Version 5.10 to 6.00:

- Higher torque/power and faster boost response in the 3500-4500RPM range for pump and E85 fuel tunes
- Finer adjustments based on the modifications installed on the vehicle (such as exhausts, intakes, and intercoolers)
- Improvements to ignition timing controls
- Charge Air Temperature sensor reading fix for MY2015 Focus ST.

Version 5.00 to 5.10:

- Improved FFS and high RPM throttle response post-shift

Version 4.10 to 5.00:

- Maps rebuilt to match the latest COBB FW released June 24, 2015.
- Further improvements to stabilize cold starting idle
- Further improved shifting and reduced rev hang
- Improved LC and FFS for easier activation
- Soft rev limiter implemented before fuel cut limiter

Version 4.00 to 4.10:

- Maps rebuilt to match the latest COBB FW released on April 8, 2015

Version 3.00 to 4.00:

- Smoother cold start and less idle hunting when the engine is still cold

Version 2.00 to 3.00:

- Much smoother shifting
- Performance optimizations in both low and top end through VCT adjustments
- Changes made to throttle mapping to improve smoothness and response

Version 1.00 to 2.00:

- Allows option for rolling map switching
- Enables both the fuel cut and throttle cut launch control limiters
- Changes made to throttle mapping to improve smoothness at low throttle inputs
- Increased torque output for all modification levels
- Increased response and quicker turbo spool for all modification levels
- Increased top-end power for all modification levels



The Options



Added Parts:

Bolt-on parts such as intakes, exhausts, intercoolers, and blow-off valves/by-pass valves are included in the base price. Only WMI kits and Big Turbos have an added cost. WMI or Big Turbo comes with complimentary Datalog Refinements at no extra charge.



Fuel Configuration (SWITCHABLE):

Unique fuel types and mixtures such as race gas, octane booster, etc. will require a ProTune.

We take advantage of the COBB AP's map switching utility allowing you to select from up to 5 different map slots using COBB Map SwitchingEach TUNE FILE from us contains UP TO 5 MAP SLOTS (not all may be used). MAP SLOTS are SWITCHABLE on the fly using your Accessport or Cruise Control buttons while TUNE FILES need to be FLASHED in the Accessport menu.

SINGLE FILE - One tune file containing either ONLY pump gas or ONLY E30 mixture.

  • Example: SINGLE FILE: 91 (slot 1) & 93 (slot 2)

Tune 1:

Slot 1 – Performance Map 91
Slot 2 – Performance Map 93
Slot 3 – SPARE MAP SLOT**
Slot 4 – SPARE MAP SLOT**
Slot 5 – SPARE MAP SLOT**

**SPARE MAP SLOTS are RESERVED for 5-Way Map Features

SEPARATE FILES - Two separate tune files; one containing ONLY pump gas and the other ONLY E30 mixture.

  • Example: SEPARATE FILES: 91 (slot 1) & 93 (slot 2) || E30 Mix (slot 1)

Tune 1:

Slot 1 – Performance Map 91
Slot 2 – Performance Map 93
Slot 3 – SPARE MAP SLOT**
Slot 4 – SPARE MAP SLOT**
Slot 5 – SPARE MAP SLOT**

Tune 2:

Slot 1 – Performance Map E30
Slot 2 – SPARE MAP SLOT**
Slot 3 – SPARE MAP SLOT**
Slot 4 – SPARE MAP SLOT**
Slot 5 – SPARE MAP SLOT**

**SPARE MAP SLOTS are RESERVED for 5-Way Map Features

SINGLE COMBO FILE - One tune file containing BOTH pump gas and E30 mixture.

  • Example: SINGLE COMBO FILE: 91 (slot 1) & 93 (slot 2) & E30 Mix (slot 3)

Tune 1:

Slot 1 – Performance Map 91
Slot 2 – Performance Map 93
Slot 3 – Performance Map E30
Slot 4 – SPARE MAP SLOT**
Slot 5 – SPARE MAP SLOT**

**SPARE MAP SLOTS are RESERVED for 5-Way Map Features


5-Way Map Features (SWITCHABLE):

SWITCHABLE on the fly.

These will be applied to the SPARE MAP SLOTS you have remaining on your tune as a result of choosing your specific Fuel Configuration. A summary of your slot configuration will be sent with the tune.

Low Boost: We set up a low-power (15 psi) map in a spare map slot for winter/poor conditions/limp home.

Eco Mode: We reduce boost to spring pressure for fuel economy.

Valet Slot: With great power comes great responsibility. In this mode, the primary rev limiter is set to 3,000 rpm and limits boost to 10 psi.

Anti-Theft Slot: In this mode, the car will start for a second and then very quickly shut off. *** If selected this will always be in the last SPARE MAP SLOT***

Example 1:

  • 5-Way Map Features: Valet + Anti-Theft
  • Fuel configuration: SINGLE COMBO FILE: 91 (slot 1) & 93 (slot 2) & E30 Mix (slot 3)

        Resulting map slot configuration:

Slot 1 – Performance Map 91
Slot 2 – Performance Map 93
Slot 3 – Performance Map E30
Slot 4 – Valet
Slot 5 – Anti-Theft


Example 2:

  • 5-Way Map Features: Valet + Anti-Theft + Low Boost
  • Fuel configuration: SINGLE COMBO FILE: 91 (slot 1) & 93 (slot 2) & E30 Mix (slot 3)

Resulting map slot configuration:

Not enough map slots. Please contact us about adjusting your selection.



Extra Options (NON-SWITCHABLE):

CANNOT be switched via map slots on the fly. APPLIES TO ALL MAP SLOTS.

Custom Shift Lights: Currently the shift lights are programmed for optimal fuel economy. This option allows you to either set your shift light to turn on at a certain RPM or you can disable it completely! Specifics will be asked in the tuning form after you place an order.

2nd Gear Torque Limit: Want more traction in 2nd gear? We can limit the torque for you here so that you don't burn through your tires!

Idle RPM Change: We can also change your idle RPM. This is particularly useful if you're running stiffer motor mounts to eliminate unwanted vibration during idle. Specifics will be asked in the tuning form after you place an order.



STuned Crackles (NON-SWITCHABLE):

CANNOT be switched via map slots on the fly. APPLIES TO ALL MAP SLOTS.

This feature adds crackling/burbling sounds to your exhaust when lifting off the throttle and coasting down in gear. The frequency and intensity of the sounds highly depend on your current engine speed during lift-off and most importantly: YOUR EXHAUST SETUP. Medium crackles have a mild intensity. Most people prefer the Loud crackles.

When purchased a separate TUNE FILE is sent containing the crackles.

This additional TUNE FILE can be used to Enable/Disable crackles or switch between crackle intensities. You must reflash from your original tune to the additional tune and vice versa.

** We have not tested all exhausts for sound quality. During testing, we found that exhaust gas temperatures have stayed relatively the same and catalytic converter temperatures had no significant increase compared to having no crackles. However, the exhaust as a whole does experience higher-intensity sound/pressure waves.**



STuned Traction Control:

Can be enabled/disabled using the Accessport menu. The intensity (or mode) of the traction control can be customized to your liking using your Accessport. KEEP IN MIND THE SYSTEM WILL REVERT BACK TO 'OPTIMAL' MODE 1 EVERY TIME YOU START YOUR CAR.

The guys and gals at COBB have implemented an ignition retard traction control system. The OEM traction control works based on applying the brakes and closing the throttle. The COBB system works by reducing output via ignition timing reduction when wheel slip is detected. It is a slick system and it works all the time while enabled on a tune. More about it here.

To further enhance the Stratified driving experience, we have refined this system by making our very own STuned Traction Control calibration.

  • Allows for the perfect amount of slip allowing the driver to modulate their pedal input without too much intrusion from the ECU
  • Proven to maintain adequate traction while keeping the driving experience exciting
  • Perfect for rainy seasons and clean launches

Check out our video demonstrating STuned Traction Control:



Throttle Mapping:

CANNOT be switched via map slots on the fly. APPLIES TO ALL MAP SLOTS.

Does not affect power. Only affects how your car will react as a result of your accelerator pedal input.

Linear: The classic Stratified feel; Smooth and Predictable.

Aggressive: 'Punchier' feel at the pedal; Smooth and Predictable with a little more kick.



Datalog Refinement:

Purpose:

  1. Enhance the performance of your Flash Tune IF AND ONLY IF there is leeway or headroom, OR make adjustments based on data logs to ensure your car operates safely with your local fuel and particular environment using a SINGLE tune iteration.
  2. To report if there are any issues and make suggestions on how to correct them (swapping parts, repairing leaks, changing fuel)
  3. If your car is running optimally on your local fuel or a particular environment, you will receive a full report on its performance.

** DISCLAIMER **: ALL CHANGES WILL BE BASED ON THE DATALOGS RECEIVED AND OUR EXTENSIVE EXPERIENCE AND EXPERTISE (THIS MEANS THAT WE WILL EITHER INCREASE PERFORMANCE OR MAKE ADJUSTMENTS FOR ENGINE SAFETY). AS SUCH, WE CANNOT AND WILL NOT GUARANTEE THAT PERFORMANCE WILL ALWAYS BE ADDED.

For more information click here



Datalog Refinement Update:

This allows us to import any changes based on a previous Datalog Refinement to your new updated tune. Please ensure to enter the correct order number associated with the Datalog Refinement that you want your updated tune to be based on.



Misc. Features:

To maximize the utility of your Stratified Flash Tune we include several setup preferences to suit your needs. These include:

Flat Foot Shifting: Allows you to shift without lifting off of the accelerator pedal. Specifics will be asked in the tuning form after you place an order.

Launch Control Settings: We can set up different launch control RPMs in Performance Map Slots. Both Fuel Cut and Throttle Cut Launch Control are included and set at the same RPM. Street tire cars have this set up between 2500 and 3500 RPM. Specifics will be asked in the tuning form after you place an order.

Sound Symposer Disable: The Focus ST sound symposer does not work well with aftermarket cat-back exhausts and becomes very noisy so we have the option to shut this off without requiring block-off plates. Specifics will be asked in the tuning form after you place an order.

Fault Code Adjustments: We can adjust any non-emissions related check engine light codes that may arise from modifications.

Active Grill Shutters: To increase airflow through the intercooler resulting in increased cooling we set it such that the active grill shutters are open for more of the time. Specifics will be asked in the tuning form after you place an order.

Check out COBB's video demonstrating some of the features listed above:











Features

  • Model: Mk3_FoST_FT_Mod_Update
  • 358 Units in Stock
  • Manufactured by: Stratified Automotive Controls
